| Number of Wires | 6 wires |
| Outside Diameter Options | 7.6mm ± 0.3mm |
| Working Temperature | -30°C to 85°C/-22°F to 185°F |
| Wire Resistance | ≤ 0.9Ω/mm |
| Screen | 1 |
| Capacitance | ≤ 80PF/m |
| Length without Reel | 100m/328.08' |
| Length with Reel | 300m/984.25' |
| Inner Shield | Tinned copper braided screen & aluminum foil-polyester tape |
| Outer Shield | Stainless steel braided screen |
| Jacket Material | PVC |
| Jacket Colour | Black |
| Cross Section | 0.314mm2 |
| AWG | 22 |
| Descriptions | With Reel | Diameter | Part No. | Shipping Weight (kg) Approx. |
| PVC cable with 6 wires | No | 7.6 | CB6-7.6-100m | 7.4 |
| PVC cable with 6 wires | Yes | 7.6 | CB6-7.6-300m | 22.8 |
