| Number of cells | 2-4 single cells |
| Input Cable Fittings | PG7: 2mm-6mm diameter cable |
| Output Cable Fittings | PG9: 4mm-8mm diameter cable |
| Trimming | Individual cell with excitation or signal trim |
| Enclosure Material | Aluminum casting |
| IP Rating | IP65 |
J04EA and J04SA Junction Box
ANYLOAD J04EA and J04SA junction and summing boxes accept inputs from multiple load cells and sum up the generated signals into a single output to ensure an accurate multi-cell balance adjustment. The J04EA and J04SA are housed in an aluminum enclosure and are designed to accommodate two to four parallel load cell connections.
- Enclosure Material: Aluminum casting
- Number of cells: 2-4 single cells
- Trimming Options: Individual cell with excitation or signal trim
- Equipped with independent potentiometers
- IP Rating: IP65
- Check the new version J04EA-16 and J04SA-16 J-BOXER Junction Box
| Load Cell Resistance | Signal Trim | Excitation Trim |
| 350Ω | 3.6% of output | 2.3% of output |
| 700Ω | 6.3% of output | 1.3% of output |
| 1000Ω | 7.0% of output | 1.0% of output |
